PTFE Graphite Packing[Kohinoor Style 62]

Construction: A special grade of PTFE bonded with quality graphite and lubricated with an inert high temperature lubricant.
Application: This packing is ideally well suited for high peripheral speeds and temperature. It can be used in pumps, valves, mixers, reactors, agitators, etc. This self-lubricating packing can be safely used in almost all chemical application including the most aggressive. Widely used in refineries, petrochemicals, fertilizers, textile industries, power plants, etc.
Available SIze: From 3mm to 45mm.
Installation: View Detail, Click Here..

Service
Parameters:
Temp.
pH
Pressure
Velocity
C
Range
Kg/cm2
Mtrs/sec
-240 to 300
0-14
300
25

Standard
Packing:
3mm to 5mm
6mm to 14mm
16mm to 19mm
Above 19mm
1/2 kg
1kg
2kg2
5kg
